Page Display Definitions
2-58
GNS-XLS Flight Management System
Rev. 3
Sep/96
HOLDING PATTERN SECTION (HOLD KEY)
HOLDING PATTERN PAGE
This page is accessed by depressing the HOLD Key when the cursor
is positioned over a Waypoint Identifier.
HOLDING PATTERN 1/1 (Page 1 of 1)
AT:
The Holding Fix and country
name or airport ident.
(Figure 2-69)
• HOLDING PATTERN
ENTRY AND STATUS
MESSAGE:
If the entry course to the
holding fix can be deter-
mined, the entry procedure
will be annunciated after all
the holding pattern parameters are entered.
• DIRECT ENTRY: indicates the system will use a direct entry to the
holding pattern. See Figure 2-70 for Direct Entry pattern.
• TEARDROP ENTRY: indicates the system will use a teardrop entry
to the holding pattern. See Figure 2-71 for Teardrop Entry pattern.
• PARALLEL ENTRY: indicates the system will use a parallel entry to
the holding pattern. See Figure 2-72 for Parallel Entry pattern.
AT DILLY
DIRECT ENTRY
INBOUND CRS 305
MAX HOLDING TAS 261
TURN DIR RIGHT
LEG TIME 1.5
LEG DIS (4.4)
EXIT MODE MANUAL
HOLDING PATTERN 1/1
<
<
<
<
Figure 2-69
To Next Page
