8. ENTER Key - DEPRESS. Identifiers listed on this page will be
transmitted to the ground via the data link.
NOTE: Wait for DATA CENTER AK message if sending multiple
requests.
9. If there are identifiers:
Placing the cursor over the
selected identifier on the ter-
minal weather and pressing
ENTER will display the
weather information for the
airport. (Figure 7-57)
10. Weather information - REVIEW.
TO INSERT A NEW IDENTIFIER:
11. Line Select - DEPRESS to position the cursor over the identifier field.
12. IDENTIFIER - INSERT. The data text fields will go blank.
13. ENTER Key - DEPRESS. The TERMINAL WX Menu Page
appears with the new identifier in place of the original identifier,
and the cursor positioned at the location of the original identifier
selected. If there is no data available for this new identifier, it will
appear in parentheses.
TO DELETE TEXT WHEN THERE IS NO DATA ENTRY IN
PROGRESS:
14. Place cursor over airport identifier on TERMINAL WX page.
15. Depress BACK key. DELETE? will appear.
16. ENTER Key- Depress to delete the airport identifier.
WINDS ALOFT MENU - DATA
UPDATE AND REVIEW
1. AFIS Key - DEPRESS to
display AFIS MENU Page.
2. Line Select Key -
DEPRESS to position cur-
sor over Option 4, WINDS
ALOFT. (Figure 7-59)
7-34
GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
KSTL 09APR90
SA: 1547 50 SCT E90
BKN 120 BKN 10 156
82 /70 /1912G18 /001
CB NW-NE
MOVG NE
TERMINAL WEATHER 1/5
Figure 7-57
AFIS MENU
<
<
<
<
1 AFIS FLT PLAN
2 SIGMETS
3 TERMINAL WX
4 WINDS ALOFT
5 RECALL AFIS FPL
6 SEND AFIS MSG
7 DISPL AFIS MSG
8 OPERATING MODES
Figure 7-59
