Honeywell GNS-XLS - Entering a Star or Profile Descent from any Stored Fpl or the Active Fpl Page

System Operation
3-27
GNS-XLS Flight Management System
Rev. 3
Sep/96
3. ENTER Key - DEPRESS.
(Figure 3-42)
4. Line Select Key -
DEPRESS to move the
cursor to shorten or
lengthen the previously
selected segment of the
airway. If applicable,
use PRV and NXT Keys
to access all airway way-
point pages.
5. ENTER Key - DEPRESS to merge the edited airway segment
into the Flight Plan and return to the Flight Plan Page.
ENTERING A STAR OR PROFILE DESCENT ON ANY STORED
FPL OR THE ACTIVE FPL PAGE
1. Line Select Key -
DEPRESS to position
cursor over ARRIVE?
field on the Flight Plan
page (Figure 3-43).
2. ENTER Key - DEPRESS
to display ARRIVAL
Page (Figure 3-44).
3. ARRIVAL Airport
Identifier - VERIFY or
INSERT valid identifier.
NOTE: If the last waypoint
on the Flight Plan is an air-
port and an Approach is pro-
grammed, the Arrival airport
identifier prefills and the cur-
sor is over the first TRANSI-
TION waypoint on the list.
If the last waypoint on the
Flight Plan is a runway, the
RUNWAY field also prefills
and the cursor is over the
first TRANSITION waypoint
on the list.
FR HQM
OED
NIECE
PYE
BSR
ZONAL
TO RZS ?
AIRWAY J501 3/3
<
<
<
<
>
Figure 3-42
KSEA - KLAX
KLAX
******
DEPART
ARRIVE? ETA
APPROACH ERASE
ACTIVE FPL 1/1
>
<
<
<
<
Figure 3-43
RUNWAY -----
TRANSITION -----
STAR -----
CIVET? EHF
HEL LHS
PGS PMD
TNP PTV
FIM FICKY
JLI GOATZ
ARRIVAL KLAX 1/1
>
<
<
<
<
<
>
>
>
>
Figure 3-44
