ADDING OR DELETING WAYPOINTS WITHIN A SID
NOTE: When a SID is modified by adding or deleting waypoints, the
sequence of waypoints is no longer identified as a SID.
To Add a Waypoint
1. Line Select Key -
DEPRESS to position
cursor over the SID way-
point identifier that will
follow the new entry on
the Flight Plan page.
See Figure 3-33.
2. Waypoint Ident - INSERT.
3. ENTER Key - DEPRESS
twice.
NOTE: The previously in-
dented SID waypoints move
over one space to the left on
the screen and are treated as
normal waypoints in the
Flight Plan. (Figure 3-34)
To Delete a Waypoint
4. Line Select Key -
DEPRESS to position
the cursor over the way-
point to be deleted on
the Flight Plan page.
5. BACK Key - DEPRESS. A DELETE? prompt will appear adja-
cent to the waypoint to be deleted.
6. ENTER Key - DEPRESS. The waypoint will be deleted and the
waypoints of the SID will be treated as non-procedure waypoints
in the flight plan.
RW16L
ELMAA
LKV
KLAX
DEPART
ARRIVE ETE
APPROACH ERASE
ACTIVE FPL 1/1
<
<
<
<
<
>
Figure 3-33
RW16L - KLAX
ELMAA
HQM
LKV
KLAX
DEPART
ARRIVE ETE
APPROACH ERASE
ACTIVE FPL 1/1
>
<
<
<
<
<
Figure 3-34
