Honeywell GNS-XLS - Loading a Gps;Gps Overlay Approach

System Operation
3-38
GNS-XLS Flight Management System
Rev. 3
Sep/96
At the MAP the pilot must manually or via the HDG Mode maneuver
the aircraft to the Missed Approach Procedure waypoint. If, after the
missed approach, an approach at a different airport is desired, erase
the current approach procedure before selecting a procedure at the
new airport. This will insure proper waypoint sequencing on the
Active Flight Plan.
LOADING A GPS/GPS OVERLAY APPROACH
1. FPL Key - DEPRESS until
the ACTIVE FPL Page
appears. (Figure 3-60)
2. Line Select Key -
DEPRESS to position
the cursor over APP-
ROACH?
3. ENTER Key - DEPRESS.
APPROACH page is now
displayed. (Figure 3-61)
4. Airport Identifier -
INSERT or VERIFY.
5. ENTER Key - DEPRESS
twice, if required, to dis-
play runway list if not
already displayed.
If a circling type approach is
desired:
Line Select Key - DEPRESS
to position cursor over TYPE.
ENTER Key - DEPRESS to display the TYPE list. Proceed to Step 10.
6. Line Select Key - DEPRESS to position cursor over desired runway.
7. ENTER Key - DEPRESS.
8. TYPE - SELECT if required.
9. ENTER Key - DEPRESS.
10. TRANSITION - SELECT if required.
11. ENTER Key - DEPRESS.
RUNWAY ------
TYPE ------
TRANSITION ------
RW21L?
RW11
APCH KPRC 1/1
>
>
Figure 3-61
KEED - KPRC
EED
DRK
KPRC
DEPART
ARRIVE ETA
APPROACH? ERASE
ACTIVE FPL 1/1
<
<
<
<
<
>
Figure 3-60
