Page Display Definitions
2-7
GNS-XLS Flight Management System
Rev. 3
Sep/96
TRANSITION:
The Transition waypoint may be prefilled or selected from a list made
available by pressing the Line Select Key adjacent to the TRANSI-
TION field.
STAR:
The Standard Terminal Arrival (STAR) can be selected from a list
made available by pressing the Line Select Key adjacent to the
STAR field.
WAYPOINTS OF STAR:
The waypoints that constitute
the STAR. (Figure 2-9)
SELECT?:
Used to select the defined
STAR. (Figure 2-9)
ERASE:
Used to erase a STAR.
(Figure 2-9 )
APPROACH Page
Accessed by pressing the Line Select Key adjacent to APPROACH
on the FLIGHT PLAN Page. With the cursor over APPROACH
press ENTER.
NOTE: Each field will prefill if there is only one choice for that partic-
ular field or Approach Airport field will flash if no Approach is avail-
able and a NO APPROACH AVAILABLE message will appear at
the bottom of the screen.
APCH:
Approach airport identifier.
This field prefills if last way-
point on the flight plan is an
airport or runway, or can be
manually entered. (Figure 2-
10)
<
RUNWAY RW06L
TRANSITION CIVET
STAR CIVET1
WAYPOINTS OF STAR:
CIVET
BREMR
ARNES
SELECT? ERASE
ARRIVAL KLAX 1/1
<
<
<
Figure 2-9
<
RUNWAY ------
TYPE ------
TRANSITION ------
RW24R
RW24L
RW07R
RW07L
‘ eraseERASE
APCH KLAX 1/2
<
<
<
<
<
<
Figure 2-10
