System Operation

3-24

GNS-XLS Flight Management System

Rev. 3

Sep/96

ENTERING AN AIRWAY FROM ANY STORED FPL OR THE

ACTIVE FPL PAGE

Enroute Airways include high altitude jet routes, low altitude and col-

ored airways.

1. Line Select Key - DE-

PRESS to position cursor

directly below the starting

waypoint of the desired

airway on the Flight Plan

page. (Figure 3-35)

2. Airway ident - INSERT.

Use:

Option 1 if the destination

waypoint is unknown.

Option 2 to enter the

known destination way-

point.

Option 1

a. # Key - DEPRESS,

then enter the airway

identifier. (Figure 3-36)

b. ENTER Key - DE-

PRESS. (Figure 3-37)

NOTE: If the waypoint above

the cursor is not a waypoint

on the selected airway, the

airway identifier will blink. The

appropriate airway or way-

point identifier must be

entered.

The Flight Plan should always

be checked for duplicate way-

points and the appropriate

waypoints deleted.

KSEA - KLAX

ELMAA

HQM

KLAX

******

DEPART

ARRIVE ETA

APPROACH ERASE

ACTIVE FPL 1/1

Figure 3-35

KSEA - KLAX

ELMAA

HQM

#J501

******

DEPART

ARRIVE ETA

APPROACH ERASE

ACTIVE FPL 1/1

Figure 3-36

RZS TO HQM ?

ZONAL HQM31

BSR TOU

PESCA FINGS

PYE ZESNB

NIECE CAFTA

COPPO YZP

OED MOCA1

SELECT ENDING WPT

AIRWAY J501 1/2

Figure 3-37
