Honeywell GNS-XLS - Reviewing a Sid from any Stored Fpl or the Active Fpl Page

System Operation
3-20
GNS-XLS Flight Management System
Rev. 3
Sep/96
9. Line Select Key -
DEPRESS to position
cursor over the desired
runway.
10. ENTER Key - DEPRESS
to select RUNWAY.
11. Departure SID Waypoints
- REVIEW (Figure 3-26),
then DEPRESS the
ENTER Key to select the
SID and insert it into
Active Flight Plan. The
display will automatically return to the ACTIVE FLIGHT PLAN
Page.
NOTE: If SID is added to a stored flight plan this display will return to
the stored flight plan page after SID is selected.
NOTE: SID waypoints appear indented from other waypoints in a
Flight Plan that are not part of a procedure. ( SID, STAR,
APPROACH)
REVIEWING A SID FROM ANY STORED FPL OR THE ACTIVE
FPL PAGE
1. Line Select Key -
DEPRESS to position
cursor over the DEPART
field on the Flight Plan
Page.
2. ENTER Key - DEPRESS
to review SID (Figure 3-
27).
3. BACK Key - DEPRESS
to return to Flight Plan
Page.
NOTE: SELECT will not appear as an option since a SID already
exists in the Flight Plan.
RUNWAY RW16L
SID ELMAA3
TRANSITION HQM
WAYPOINTS OF SID:
ELMAA
HQM
SELECT? ERASE
DEPARTURE KSEA 1/1
>
>
>
Figure 3-26
RUNWAY RW16L
SID ELMAA5
TRANSITION HQM
WAYPOINTS OF SID:
ELMAA
HQM
ERASE
DEPARTURE KSEA 1/1
>
>
>
Figure 3-27
