Page Display Definitions
2-31
GNS-XLS Flight Management System
Rev. 3
Sep/96
RAIM/FDE?:
Indicates RAIM and/or FDE is AVAILable or UNAVAILable.
SATS TRACKED:
Indicates the number satellites presently being tracked.
GPS SUBSECTION 3/3 (Page 3 of 3)
Pressing the NXT Key again
will display the third GPS
SUBSECTION Page and the
following can be observed.
This page displays the GPS
receiver status. The GPS
receiver is an 8 channel
receiver, therefore, up to 8
lines of satellite information
is displayed. The information
displayed is as follows:
(Figure 2-37)
GPS SAT:
This is the satellite (PRN) number.
AZ:
This is the satellite azimuth position displayed in degrees.
EL:
Satellite elevation displayed in degrees above the horizon.
SNR:
This the received signal-to-noise ratio for each satellite.
HLTH:
Satellite health is displayed as BAD or GOOD.
T:
YES or NO displayed as to whether this satellite is presently being
tracked.
SAT AZ EL SNR HLTH T
-- --- -- --- ---- -
14 304 71 44 GOOD Y
15 214 23 40 GOOD Y
22 124 47 44 GOOD Y
25 46 35 43 GOOD Y
29 304 40 40 GOOD Y
18 288 10 36 GOOD Y
-- --- -- -- ---- -
GPS SUBSECTION 3/3
Figure 2-37
