Honeywell GNS-XLS - OPERATING MODES Page; Satellite Data Communications System); Auto Report

REGION: The four satellite
regions, West Atlantic, East
Atlantic, Pacific Ocean and
Indian Ocean, that AFIS inter-
faces with to establish a data
link with the Global Data Center.
(Figure 7-31)
LINK:
OPERATIONAL: Message indi-
cating the SAT COMM link is
enabled.
NONE: Current position does
not correspond with the manual-
ly selected boundaries or satel-
lite link is not operational.
ACTIVATE?: Use to enable
satellite network in AUTO or
MAN. (Figure 7-32)
OPERATING MODES PAGE (FOR AFIS USERS NOT EQUIPPED
WITH SATELLITE DATA COMMUNICATIONS SYSTEM)
Operating Modes information is accessed by selecting Option 8 on
the AFIS MENU Page.
AUTO REPORT:
ON: The aircraft will automatically report position and station ID
for weather updates to the Global Data Center via the data link on a
timed basis.
OFF: The automatic reporting capability has been manually inhibit-
ed by the pilot.
7-21
GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
AFIS OPERATING MODES
SAT LINK CONTROL
SAT COM: MAN
REGION: W. ATLANTIC
LINK:ACTIVATE?
Figure 7-32
AFIS OPERATING MODES
SAT LINK CONTROL
SAT COM: MAN
REGION: E. ATLANTIC
LINK:OPERATIONAL
$
%
Figure 7-31
