Honeywell GNS-XLS - Reviewing Waypoint Data;Coordinates (Flight Plan Pages Only)

System Operation
3-12
GNS-XLS Flight Management System
Rev. 3
Sep/96
waypoint nearest the air-
craft position will be dis-
played first.
To select an alternate way-
point location:
2. PRV or NXT Key -
DEPRESS until desired
country name is dis-
played. (Figure 3-15)
3. ENTER Key- DEPRESS
to add the waypoint to
the flight plan.
REVIEWING WAYPOINT DATA/COORDINATES (FLIGHT PLAN
PAGES ONLY)
If the stored flight plan is currently displayed, proceed to Step 4.
To access the desired flight plan:
1. FPL Key - DEPRESS to locate the desired Flight Plan on the
FLIGHT PLAN LIST Pages.
2. Line Select Key - DEPRESS to position the cursor over desired
Flight Plan Number.
3. ENTER Key - DEPRESS.
4. Line Select Key - DEPRESS to position cursor over identifier to be
reviewed.
5. ENTER Key - DEPRESS.
6. Waypoint Coordinates or data- VERIFY.
7. ENTER Key - DEPRESS. The Flight Plan is displayed with the
cursor over the next waypoint.
8. Repeat Steps 5 through 7 for remaining waypoints.
NOTE: This procedure may also be used for reviewing waypoint
information on the Active Flight Plan Page.
WAYPOINT TRM
PORTU
POS N 38 45.60
W027 05.60
FREQ 116.20
VAR W 14
ELEV 172
NDB-ENTER
DATABASE WPT 2/8
Figure 3-15
