GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
TURNING VHF NETWORK ON
1. AFIS Key - DEPRESS to display AFIS MENU Page.
2. Line Select Key -
DEPRESS to position cur-
sor over Option 8, OPER-
ATING MODES.
3. ENTER Key - DEPRESS.
4. Line Select Key - DEPRESS
to position cursor over OFF
option of VHF NETWORK
field. (Figure 7-94)
5. BACK Key - DEPRESS.
ON? appears in the cursor.
(Figure 7-95)
6. ENTER Key - DEPRESS to
turn VHF network on. VHF
LINK CONTROL Page
appears. (Figure 7-96)
NOTE: The ACTIVE LINK
information at the bottom of the
page indicates the network that
is being serviced at that time.
7. Line Select Key -
DEPRESS to position cur-
sor over AUTO option of
desired ground network.
AFIS OPERATING MODES
AUTO REPORT ON
AUTO WX UPDT ON
VHF NETWORK OFF
SAT NETWORK ON
ACTIVE LINK: SATCOM
>
>
>
Figure 7-94
AFIS OPERATING MODES
AUTO REPORT ON
AUTO WX UPDT ON
VHF NETWORK ON ?
SAT NETWORK ON
ACTIVE LINK: ARINC
>
>
>
Figure 7-95
AFIS OPERATING MODES
>
>
VHF LINK CONTROL
ARINC AUTO
SITA/AVICOM AUTO
AIR CANADA AUTO
Figure 7-96
