Page Display Definitions
2-51
GNS-XLS Flight Management System
Rev. 3
Sep/96
• NEED ACTIVE FPL: This will be displayed if there are less than two
waypoints on the active flight plan.
• BACK FOR NEXT WPT: Displayed when the cursor is over the start
or end waypoint field.
• PRED IN PROGRESS: This is displayed when an FDE prediction is
in progress. All other fields are disabled at this point.
• PREDICTION UNAVAIL: This will be displayed if the GPS is not in
the idle state or the aircraft is not on the ground.
FDE EXCLUDE SATS 1/1 (Page 1 of 1)
This page is accessed by
placing the cursor over the
EXCLUDE SATS (QTY x)
field on PLAN 7/8 Page and
pressing ENTER.
EXCLUDE SATS LIST:
The designated satellite num-
ber being excluded from the
FDE prediction is listed here.
SAT #:
The desired satellite being excluded from FDE prediction is entered by
pressing the Line Select Key by this field and entering the number of
the satellite. Press ENTER to add the satellite to the list. Entering a
number already listed and pressing ENTER will remove the number
from the list. Pressing the Line Select Key next to CLEAR ALL and
pressing ENTER will remove all satellites from the exclusion list.
PLAN 8/8 (Page 8 of 8) FDE COMPUTATION
COMPUTING - STANDBY:
This display will flash while
FDE prediction is being cal-
culated. See Figures 2-61
xx% COMPLETE:
The number displayed is the
percentage of calculation
completed.
EXCLUDED SATS LIST
12 14 02 16 19 22 07
SAT #02
CLEAR ALL
OK? ENTER
FDE EXCLUDE SATS 1/1
<
<
Figure 2-60
FDE COMPUTATION
COMPUTING - STANDBY
51% COMPLETE
CANCEL COMPUTE
PLAN 8/8
<
Figure 2-61
