3. ENTER Key - DEPRESS. The INITIALIZE Page is displayed.
The AFIS initialization data can be modified at this time. Refer to
AFIS INITIALIZATION at the beginning of this SYSTEM OPERA-
TION section.
SENDING AND RECEIVING AFIS MESSAGES
Refer to the discussions in Section 7 on sending and receiving AFIS
messages.
STATION REVIEW/UPDATE
There are two types of station
pages, depending on the sys-
tem configuration. The system
may be configured for a J32,
J41 or EMB120 aircraft.
J32 AIRCRAFT CONFIGU-
RATION:
1. AFIS Key - DEPRESS, if
necessary, to display the AFIS MENU Page.
2. Line Select Key -
DEPRESS to position the
cursor over STATION.
See Figure 8-77.
3. ENTER Key - DEPRESS.
The STATION MENU Page
is displayed. See Figure 8-
78.
4. Line Select Key -
DEPRESS to position the
cursor in the ETA field.
NOTE: The Line Select Keys may be used at any time to enter or
change data.
5. INSERT the estimated time of arrival in GMT, hours,minutes.
This field may be left blank.
NOTE: Entry of an invalid time will result in the field blinking.
8-61
GNS-XLS FMS with Regional Airline AFIS
Rev 8
Apr/00
>
20:09 AFIS MENU
<
><
<
< >
WGT/BAL CLOSE OUT
STATION INITIALIZE
WEATHER DVT/HOLD
DISPATCH
AIRPORT ANALYSIS
SEND MSG
DISPLAY MSG
<
Figure 8-77
20:21 STATION MENU
><
<
< >
<
>
>
>
ETA DETAILING
FUEL WINDSHIELD
DEICE
GPU
UM
s WC A S
TRANSMIT
Figure 8-78
