GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
13. CRUISE MODE - VERIFY or
INSERT an amended cruise
mode.
14. ENTER Key - DEPRESS.
The cursor positions over
TRANSMIT REQUEST?
field. (Figure 7-127)
15. ENTER Key - DEPRESS to
initiate a Flight Plan Update.
ACTIVE FPL Page will
appear.
NOTE: For aircraft equipped with the Antenna Switching Unit, if DATA
LINK DISABLED message appears DEPRESS momentary AFIS
annunciator to enable the air to ground data link. Also enable VHF or
satellite network.
Wait for DATA CENTER AK message if sending multiple requests.
SELECTING UPDATE AS ACTIVE FLIGHT PLAN
1. FPL Key - DEPRESS until
AFIS FLIGHT PLAN LIST
Page appears with Updated
Flight Plan (UPDA - XXXX).
(Figure 7-128)
2. Line Select Key - DEPRESS
to position cursor over
Updated Flight Plan.
3. ENTER Key - DEPRESS.
Cursor positions itself over
REPLACE ACTIVE FPL?
4. ENTER Key - DEPRESS to
replace Active Flight Plan
with Updated Flight Plan.
(Figure 7-129)
5. ACTIVE FPL - CONFIRM.
Updated Flight Plan
becomes the Active Flight
Plan.
ACTUAL FL 410
ASSIGNED FL 370
PAYLOAD 1200
FUEL REM 11985
CRUISE MODE M80
TRANSMIT REQUEST?
AFIS FPL UPDATE
Figure 7-127
FLIGHT PLAN LIST 1/4
CYUL-KJFK 06APR9O
UPDA-KORD 16APR90
REPLACE ACTIVE FPL?
AFIS
<
<
Figure 7-128
AFIS
<
<
FLIGHT PLAN LIST 1/4
CYUL-KJFK 06APR9O
UPDA-KORD 16APR90
REPLACE ACTIVE FPL?
Figure 7-129
