Rev. 3
Sep/96
TURNING SATELLITE NETWORK ON
The satellite network must be
turned ON to send non-flight
related messages. Since the
VHF network has precedence
over the satellite network in areas
of shared coverage, the VHF
NETWORK must be turned OFF
in order for SATCOM to be the
Active Link. If the VHF network
cannot be received and the SAT-
COM mode is set to ON the sys-
tem will automatically select the
SATCOM mode for transmit and
receive.
1. AFIS Key - DEPRESS to dis-
play AFIS MENU Page.
2. Line Select Key - DEPRESS
to position cursor over Option
8, OPERATING MODES.
3. ENTER Key - DEPRESS.
4. Line Select Key - DEPRESS
to position cursor over OFF
option of SAT NETWORK
field. (Figure 7-102)
5. BACK Key - DEPRESS.
ON? appears in the cursor.
(Figure 7-103)
NOTE: The ACTIVE LINK infor-
mation at the bottom of the page
indicates the network that is
being serviced at that time.
6. ENTER Key - DEPRESS to
turn satellite network on.
SAT (satellite) LINK
CONTROL Page appears
with cursor over AUTO. (Figure 7-104)
DEPRESS ENTER Key to cursor through option fields and return to
AFIS OPERATING MODES Page or proceed to Step 7.
7-52
GNS-XLS Flight Management System AFIS Operation
AFIS OPERATING MODES
SAT LINK CONTROL
SAT COM: AUTO
REGION: W. ATLANTIC
LINK:OPERATIONAL
$
%
Figure 7-104
AFIS OPERATING MODES
AUTO REPORT ON
AUTO WX UPDT ON
VHF NETWORK OFF
SAT NETWORK ON ?
ACTIVE LINK: SATCOM
>
>
>
Figure 7-103
AFIS OPERATING MODES
AUTO REPORT ON
AUTO WX UPDT ON
VHF NETWORK OFF
SAT NETWORK OFF
ACTIVE LINK: NONE
>
>
>
Figure 7-102
