NOTE: Once the system is initialized, the page appears between the
Active Flight Plan Page and the first GNS-X
LS
FLIGHT PLAN LIST
Page.
AFIS FLT PLAN LIST: A list of
AFIS generated Flight Plan ori-
gin/destination identifiers with
date of issue. (Figure 7-2)
NOTE: Additional pages can
be accessed when more than 6
Flight Plans are listed by
DEPRESSING the FPL Key to
access page.
LOADING FLIGHT PLAN:
The system is loading a select-
ed AFIS Flight Plan.
REPLACE ACTIVE FPL?: Allows a selected AFIS Flight Plan to
replace an existing Active Flight Plan.
UPDA-XXXX: (Where XXXX is an ident) Indicates a Flight Plan
Update for an active Flight Plan has occurred.
FLIGHT PLAN PROGRESS (NAVIGATION PAGE 5)
HEC:KVNY: Current FROM
and TO waypoints. (Figure 7-
3) The FROM waypoint can be
replaced by DIR TO for
DIRECT TO.
FL: AFIS planned flight level
for leg being flown.
NOTE: Field is dashes when
aircraft is projected to be climb-
ing or descending.
PLAN: Planned
This column is AFIS planned data either transferred from the disk or
received via the data link.
7-4
GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
FLIGHT PLAN LIST 1/4
KABE-KVNY 04JAN9O
KAPA-KTEB 04JAN90
KBUR-KLGA 04JAN90
KBZN-KLAN 04JAN90
KDAL-KDEN 04JAN90
KDAL-KJFK 04JAN90
AFIS
<
<
<
<
Figure 7-2
HEC:KVNY FL390
PLAN ACT
F REM 2150 3380
FF P/E 625 0
ETA 00:06 18:52
TAS 460 460
GS 448 460
WIND 330/ 40 360/ 0
NAVIGATION 5/5
<
Figure 7-3
