Database Update
5-1
GNS-XLS Flight Management System
Rev. 3
Sep/96
SECTION 5
DATABASE UPDATE
DATA BASE UPDATE PROCEDURES
1. Apply aircraft power.
2. Turn the screws located directly above both lower DZUS fasten-
ers counter-clockwise. The screws will remain in the door.
Carefully lift the door.
3. Insert current Data Base
Update card firmly into
the slot. The double row
of holes on the forward
edge of the card must be
inserted first, with the
write protect slot toward
the left edge of the card.
Insert the card at the
same level as the eject
button located at the left
edge of the slot.
4. ON Key - DEPRESS to turn on system. Figure 5-1 appears.
TO UPDATE
CAUTION: IF AN INTERRUPTION OF THE UPDATE PROCESS IS
DESIRED, REMOVE THE UPDATE DISK. DO NOT TURN OFF
POWER TO STOP THE UPDATE.
5. Line Select or 1 Key -
DEPRESS to select
BEGIN UPDATE, if
required. If update is not
desired, depress the
Line Select or 2 Key to
select restart NAV.
6. With cursor over option
1, ENTER Key -
DEPRESS. The Update
- Data Base Page and,
the message “X” %
“COMPLETE” appear
indicating the update is in progress. (Figure 5-2)
TYPE:WW CARD:1/1
REVISION: 3-95
EXPIRES: 13 MAR 95
ENTER CHOICE:
1 BEGIN UPDATE
2 RESTART NAV
(REMOVE CARD)
DATA BASE UPDATE
<
<
Figure 5-1
TYPE:WW CARD:1/1
REVISION: 3-95
EXPIRES: 13 MAR 95
2% COMPLETE
DATA BASE UPDATE
<
<
Figure 5-2
