Honeywell GNS-XLS User Manual

7-60
GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
UPDATING AFIS FLIGHT PLAN AND WEATHER
UPDATING AFIS FLIGHT PLAN
1. FPL Key - DEPRESS to dis-
play Active Flight Plan Page.
2. Active Flight Plan - VERIFY
the Active Flight Plan route or
AMEND as necessary.
3. Line Select Key - DEPRESS
until cursor is positioned over
AFIS UPDATE? (Figure 7-
125)
4. ENTER Key - DEPRESS.
AFIS FPL UPDATE Page
appears with cursor posi-
tioned over ACTUAL FL
value field. (Figure 7-126)
NOTE: Values entered are
checked against aircraft limita-
tions stored in GDC computers.
Invalid entries prevent cursor
movement and cause the field to
flash. Amend and re-enter to
advance cursor.
NOTE: SIGMETS Winds and Terminal Wx are automatically updated
when a AFIS FPL update is received.
5. ACTUAL FL value - VERIFY or INSERT actual flight level.
6. ENTER Key - DEPRESS.
7. ASSIGNED FL value - VERIFY or INSERT new flight level assign-
ment.
8. ENTER Key - DEPRESS.
9. PAYLOAD value - VERIFY or INSERT amended payload value.
10. ENTER Key - DEPRESS.
11. FUEL REM value - VERIFY or INSERT amended fuel remaining
value.
12. ENTER Key - DEPRESS.
ACTIVE FPL 1/1
FR RW19R ----- 1
TO ORD ----- 2
AZO ----- 3
KDTW ----- 4
******
DEPART AFIS UPDATED
ARRIVE ETE
ERASE ERASE
<
<
<
<
<
>
Figure 7-125
ACTUAL FL
ASSIGNED FL
PAYLOAD
FUEL REM
CRUISE MODE
AFIS FPL UPDATE
Figure 7-126
