3. ENTER Key - DEPRESS to
display WINDS ALOFT
Menu Page. (Figure 7-60)
4. Line Select Key -
DEPRESS to position cur-
sor over the desired Wind
identifier.
5. ENTER Key - DEPRESS.
If the desired identifier is
enclosed in parentheses,
pressing the ENTER Key will
cause it to blink, indicating no weather information is available for that
identifier.
If no identifiers are displayed, they may be inserted by pressing the
Line Select Key, which will create a cursor over the first blank identifi-
er position. INSERT an identifier. (Usually a VOR or intersection)
6. ENTER Key - DEPRESS
7. Line Select Key - DEPRESS to position cursor over TRANSMIT
REQUEST?
8. ENTER Key - DEPRESS.
Identifiers listed on this
page will be transmitted to
the ground via the data link.
NOTE: Wait for DATA CENTER
AK message if sending multiple
requests.
9. If there are identifiers, upon
depressing the ENTER Key,
the WINDS ALOFT Data
Pages pertaining to the
selected identifier appear.
(Figure 7-61)
10. Wind information -
REVIEW.
TO INSERT A NEW IDENTIFIER:
11. Press Line Select Key to position the cursor over the identifier
field.
12. IDENTIFIER - INSERT. The data text fields will go blank.
7-35
GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
<
<
<
<
KSNA (ENO)
KSTL (DQO)
(MKC)
TRANSMIT REQUEST?
AFIS WINDS ALOFT
>
>
>
>
Figure 7-60
ICT 122356Z
18000 310/23-17
24000 290/34-31
30000 290/44-47
34000 300/53-54
39000 310/68-56
45000 310/57-59
WINDS ALOFT
Figure 7-61
To Next Page
