AFIS FLT PLAN PAGE 2

WEIGHTS, FLIGHT LEVEL

AND ROUTE

RAMP WT: Planned ramp

weight in lbs prior to starting

engines as transferred from disk

or received via the data link.

(Figure 7-10)

GROSS WT: Sum of basic

operating weight, payload, and

fuel remaining as calculated by

GNS-XLS. (Figure 7-11)

NOTE: RAMP WT changes to

GROSS WT if there is an auto-

matic FUEL FLOW input, FUEL

REMAINING quantity, and

input for basic operating weight

and PAYLOAD input.

FPL LDWT: Flight planned

landing weight of aircraft at des-

tination as transferred from disk

or received via the data link.

FLT LVL: Planned flight

level(s) as transferred from disk or received via the data link.

ROUTE: Planned route of flight as computed by Global Data Center

and transferred from disk or received via the data link.

NOTE: Pressing the AFIS or NXT Key displays the remainder of the

route (up to 50 waypoints).

UPDATE: Waypoint identifier defining position of aircraft at time of

last update request.

7-9

GNS-XLS Flight Management System AFIS Operation

Rev. 3

Sep/96

RAMP WT 30365

FPL LDWT 21559

FLT LVL 410/450

ROUTE

KSNA-HEC-PGS-DBL-

CYS-J148-ONL-J94-

DBQ-GIJ-J554-CRL-

PSB-KJFK

AFIS FLT PLAN 2/4

Figure 7-10
