Rev. 3
Sep/96
Description
1-8
GNS-XLS Flight Management System
Magenta Lateral TO Waypoint, Vertical TO Waypoint,
and TO Waypoint
Yellow FROM Waypoint
Caution Messages
Data entered, but not yet accepted by the computer.
Cyan Date and Times
Tuned Frequencies or Codes
Altitudes
Green Navigation and Fuel Data
General Page Data
White Page Titles and Prompts
Red Warnings
Blue Waypoint Numbers
COLORS:
The CDU displays are color coded to assist the operator in recogniz-
ing information. The following is a list of these colors and their mean-
ings:
