TERMINAL WX DATA PAGES
These pages are accessed by
selecting a terminal weather
identifier on the TERMINAL
WEATHER Menu Page.
They allow review of Terminal
Weather by identifier as trans-
ferred from disk or received by
the Global Data Center via the
data link.
DATE: Issue date of actual
weather. This field may be blank
if transferred from disk.
Weather available for review includes:
• SA (Sequence Reports)
• FT (Terminal Forecasts)
• NOTAMS (Notices to Airmen)
• PIREPS (Pilot Reports)
WINDS ALOFT PAGES
The AFIS WINDS ALOFT
Menu Page is accessed by
selecting Option 4 on the AFIS
MENU Page.
The WIND identifiers represent
VOR, airport, waypoint, Lat/Lon
or VORTAC locations, for
which associated weather data
is available.
WINDS ALOFT DATA PAGES
These pages are accessed by
selecting a wind identifier on the WINDS ALOFT MENU page.
They allow review of Winds Aloft data by VOR, airport, waypoint,
Lat/Lon or VORTAC identifier as transferred from disk or received via
the data link.
7-13
GNS-XLS Flight Management System AFIS Operation
Rev. 3
Sep/96
KSNA
SA: 1846 -X 200 SCT
6H 71/61/2015/990/H3
FT: 071919 -X 250
SCT 1912. 03Z C200
BKN. 13Z MVFR H..
NOTAMS: !SNA 01/004
TERMINAL WEATHER 1/3
Figure 7-19
(SNA ) (ENO )
(STL ) (DQO )
(MKC )
TRANSMIT REQUEST?
AFIS WINDS ALOFT
<
<
<
<
>
>
>
>
Figure 7-20
