Rev. 3
Sep/96
7-40
GNS-XLS Flight Management System AFIS Operation
f. The Line Select Key moves cursor to SEND MESSAGE?
field if a TO or # entry field has been inserted.
g. Top two left Line Select keys move cursor up and down
page.
11. Line Select Key - DEPRESS
to position over SEND MES-
SAGE? It will be necessary
to press the ENTER Key
after 15 lines of text, or if
there are two succeeding
blank lines, in order for the
cursor to appear over SEND
MESSAGE? field. (Figure
7-72)
12. ENTER Key - DEPRESS.
The message is sent to the
Global Data Center via the
data link.
NOTE: Wait for DATA CENTER AK message if sending multiple
requests.
TO RETURN TO THE AFIS MENU PAGE
13. Press AFIS or NXT Key with the cursor off the page.
SEND AFIS MSG
DELAYED DUE TO WX
NEW ETA IS 1430Z
PLS ARR GND TRANS
ALSO PLS HAV MECH
AVAIL TO DISCUSS POS
MAINT PROB
SEND MESSAGE?
<
>
>
$
%
Figure 7-72
