11. Arrival STAR Waypoints
- REVIEW (Figure 3-47),
then DEPRESS ENTER
Key to insert STAR into
Active Flight Plan and
return to the ACTIVE
FLIGHT PLAN Page.
NOTE: Look carefully at the
flight plan to see if any way-
points are out of sequence.
Delete waypoints as neces-
sary.
STAR waypoints appear indented from the other waypoints on a
Flight Plan that are not part of a procedure. (SID, STAR, or
APPROACH)
REVIEWING A STAR FROM A STORED FPL OR THE ACTIVE
FPL PAGE
1. Line Select Key -
DEPRESS to position
cursor over the ARRIVE
field on the FLIGHT
PLAN Page.
2. ENTER Key - DEPRESS
to review STAR. (Figure
3-48)
3. BACK Key - DEPRESS
to return to FLIGHT
PLAN Page.
NOTE: SELECT will not appear as an option since a STAR already
exists in the Flight Plan.
EDITING A STAR FROM A STORED FPL OR THE ACTIVE FPL PAGE
1. Line Select Key - DEPRESS to position cursor over the ARRIVE
field on the FLIGHT PLAN Page.
2. ENTER Key - DEPRESS.
3. Line Select Key - DEPRESS twice to position the cursor over the
STAR field. This will erase the current TRANSITION.
RUNWAY -----
TRANSITION AVE
STAR MOOR3
WAYPOINTS OF STAR:
AVE FIM
DERBB PAULA
REYES ILEAN
PIRUE WAKER
ERASE
ARRIVAL KLAX 1/1
>
>
>
Figure 3-48
RUNWAY -----
TRANSITION AVE
STAR MOOR3
WAYPOINTS OF STAR:
AVE FIM
DERBB PAULA
REYES ILEAN
PIRUE WAKER
SELECT? ERASE
ARRIVAL KLAX 1/1
>
>
>
Figure 3-47
