Honeywell GNS-XLS User Manual

System Operation
3-40
GNS-XLS Flight Management System
Rev. 6
Jul/98
8. ENTER Key - DEPRESS
twice to engage Heading
Select mode. (Figure 3-
64)
After receiving the final
intercept vector from
ATC:
9. HDG Key - DEPRESS to
display the HEADING
VECTOR Page. (Figure
3-65)
10. ENTER Key - DEPRESS.
11. BACK Key - DEPRESS
to display INTERCEPT?
12. ENTER Key - DEPRESS
cursor moves to the TO
field.
13. BACK Key - If Required,
DEPRESS until the FAF
waypoint is displayed.
14. ENTER Key - DEPRESS cursor moves to the DTK field.
15. Final Approach Course - INSERT if a Procedure Turn type
approach or VERIFY if any other type approach.
16. ENTER Key - DEPRESS twice.
17. CDI Display - VERIFY the HSI course needle slews to the final
approach course or manually select the course.
18. Approach Annunciator - When over the FAF, VERIFY annuncia-
tion and the HSI scaling output has changed to APPR on NAVI-
GATION Page 2.
HDG 155
INTERCEPT ?
FAF
TO DRK DTK 197
OK? ENTER
HEADING VECTOR 1/1
>
<
<
<
Figure 3-65
HDG 155
HDG SELECT ?
TO DRK DTK 197
OK? ENTER
HEADING VECTOR 1/1
>
<
<
<
Figure 3-64
