System Operation
3-56
GNS-XLS Flight Management System
Rev. 3
Sep/96
NOTE: The
d
function may also be used to initiate a Pseudo-
VORTAC. Following the Direct To entry using the
d
Key the dis-
play automatically advances to NAVIGATION Page 1. Manually
position the cursor over DTK field and continue as described above
in Steps 5 and 6. To exit Pseudo-VORTAC Mode make any leg
change (e.g.
d
Key press and enter current TO waypoint). When
exiting Pseudo-VORTAC the system may return to the -AUTO- Leg
Change Mode unless the system was in -MAN- prior to initiating
Pseudo-VORTAC.
A manual leg change means the system will not automatically
sequence to the next waypoint on the active flight plan. To sequence
to the next waypoint in the flight plan, use the Direct To function or
place the cursor over -MAN-. Press the BACK Key and AUTO? will
be displayed. Press the ENTER Key and the system will return to
the automatic leg change mode.
