Honeywell GNS-XLS User Manual

System Operation
3-97
GNS-XLS Flight Management System
Rev. 3
Sep/96
2. Line Select Key -
DEPRESS to position
the cursor over the TRIP
PLAN field.
3. Desired Flight Plan -
INSERT Flight Plan
Number (Figure 3-157)
or “A” for Active Flight
Plan. (Figure 3-158).
4. ENTER Key - DEPRESS.
NOTE: If a Flight Plan num-
ber is left in the TRIP PLAN
field and not returned to “A”,
no updated Active Flight
Plan information will be dis-
played. Figures 3-156 and 3-
157 show how the screen
appears when an Active FPL
has been selected and the
airplane is airborne.
5. FR Waypoint - VERIFY
or INSERT as required.
(Figure 3-159)
6. ENTER Key - DEPRESS.
7. TO Waypoint - VERIFY
or INSERT as required.
TRIP PLAN A
DIRECT KDAL
TO LIT KHPN
GS 407
DIS/DTK -----/---
ETE ------
FPL -----/-----
>
>
<
PLAN 2/8
Figure 3-158
TRIP PLAN 6
DIRECT KDAL
TO LIT KHPN
GS 407
DIS/DTK -----/---
ETE ------
FPL -----/-----
>
>
<
PLAN 2/8
Figure 3-157
TRIP PLAN 6
FR KDAL KDAL
TO ---- KHPN
GS 407
DIS/DTK -----/---
ETE ------
FPL ------/------
>
>
<
PLAN 2/8
Figure 3-159
