System Operation
3-101
GNS-XLS Flight Management System
Rev. 3
Sep/96
DEPRESS to position
the cursor over the
FUEL PLAN field.
3. Desired Flight Plan -
INSERT Flight Plan
Number (Figure 3-165)
or “A” for Active Flight
Plan.
4. ENTER Key - DEPRESS.
NOTE: If a flight plan num-
ber is left in the Fuel Plan
field and not returned to “A”,
no updated Active Flight
Plan information will appear.
5. FR Waypoint - VERIFY
(Figure 3-166) or
INSERT as required.
6. ENTER Key - DEPRESS.
7. TO Waypoint - VERIFY
or INSERT as required.
NOTE: With FUEL PLAN A
selected the FUEL PLAN
leg automatically advances
to display DIRECT TO the
NAVIGATION Page TO
waypoint each time the
FUEL PLAN or TRIP PLAN
Page is accessed.
8. ENTER Key - DEPRESS
twice to display LEG and
FPL FUEL information.
(Figure 3-167).
9. Groundspeed - VERIFY.
The current aircraft
groundspeed is displayed unless a manual entry is made.
FUEL PLAN 3
DIRECT KDAL
TO LIT KHPN
GS 450
FLOW 1200
LEG FUEL ------
FPL FUEL ------
>
>
PLAN 3/8
<
Figure 3-165
FUEL PLAN 3
FR KLAX KLAX
TO ----- KMDW
GS 434
FLOW (MAN) 1200
LEG FUEL ------
FPL FUEL ------
>
>
PLAN 3/8
<
Figure 3-166
FUEL PLAN 3
FR KLAX KLAX
TO DAG KMDW
GS 425
FLOW (MAN) 1200
LEG FUEL 324
FPL FUEL 4504
>
>
PLAN 3/8
<
Figure 3-167
