System Operation
3-108
GNS-XLS Flight Management System
Rev. 3
Sep/96
7. ENTER Key - DEPRESS.
If Waypoint Page Appears:
a. Waypoint Page Co-
ordinates - VERIFY
Database Waypoint
or INSERT Waypoint
Data. (Figure 3-174)
To Insert Waypoint
Coordinates (cursor over
POS Field):
(1) Latitude - IN-
SERT (N or S
first, then de-grees, minutes, and hundredths).
(2) ENTER Key - DEPRESS.
(3) Longitude - IN-SERT (E or W first, then de-grees, min-
utes, tenths and hundredths).
b. ENTER Key - DEPRESS.
8. DIS, DTK - CHECK.
NOTE: The Pilot Entered
Leg Change procedure
inserts a “fence” indicated by
(----) on the DIRECT TO
and ACTIVE FPL pages pre-
venting Auto Leg Change
beyond the TO waypoint, if
the TO waypoint was not on
the original Active Flight Plan
(Figure 3-175) The MSG
light illuminates and the
SYSTEM MESSAGE Page
displays NO AUTO LEG
CHG, however the AUTO field on NAVIGATION Page 1 continues to
display AUTO.
To jump the fence and continue with the flight plan use the
d
Key
then the Line Select Keys to positionthe cursor over a way point
beyond the fence then press
ENTER
Key
WAYPOINT CORLA
POS N 33 38.30
W116 16.70
NDB-ENTER
DATABASE WPT 1/1
Figure 3-174
<
<
<
<
FR HEMET 7
TO CORLA 00:20 8
------
KSNA -KDTW
MUSEL
HEMET
DEPART
ARRIVE ETA
APPROACH ERASE
>
>
ACTIVE FPL 1/2
>
Figure 3-175
To Next Page
