Page Display Definitions
2-11
GNS-XLS Flight Management System
Rev. 5
Sep/97
DEPART:
Same as stored Flight Plan Page.
ARRIVE:
Same as stored Flight Plan Page.
APPROACH:
Same as stored Flight Plan Page.
ETA: (ETE/DIS/ALT)
Estimated Time of Arrival at
each waypoint on the Active
Flight Plan based on current
groundspeed. (Figure 2-15)
NOTE: When the cursor is
placed over the ETA field and
the BACK Key is pressed,
ETE, DIS, or ALT can be dis-
played. Press ENTER to
select the desired option. No
ETE, ETA, ALT or DIS infor-
mation is displayed for waypoints beyond the missed approach "fence"
(++++++) or the flight plan discontinuity (------).
ETE:
Estimated Time Enroute between waypoints on the Active Flight Plan
based on current groundspeed.
DIS:
Distance between each way-
point on the Active Flight
Plan.
ALT:
Constraint altitude and way-
point offset of programmed
VNAV waypoints for applica-
ble waypoints on the Active
Flight Plan (Figure 2-16).
<
<
ACTIVE FPL 1/2
DIRECT
TO KHART 19:37
19DFW 19:49
ELD 20:13
MEI 21:03
DELBE 21:22
DEPART
ARRIVE ETA
APPROACH ERASE
<
Figure 2-15
<
<
<
<
ACTIVE FPL 2/2
RYMES -10 3000
ISLET 2000G
MAPRW34 435G
++++++
HP CMK
******
DEPART
ARRIVE ALT
APPROACH ERASE
<
Figure 2-16
