Page Display Definitions
2-23
GNS-XLS Flight Management System
Rev. 3
Sep/96
VLF SUBSECTION 3/4 (Page 3 of 4)
Pressing the NXT Key again will display the third VLF SUBSECTION
Page and the following can be observed.
Column 1: (Figure 2-27) VLF COMM Stations
• WSH: Jim Creek, Washington
• AUS: Northwest Cape, Australia
• ANT: Anthorne, England
• MNE: Cutler, Maine
• HAW: Lualualei, Hawaii
• JPN: Yosami, Japan
• GBR: Rugby, England or
• ANN: Annapolis, Maryland
Column 2:
The station amplitude rang-
ing from 01 (minimum
acceptable) to 99 (maximum
strength). Dashes (-) indicate
the station amplitude is less
than the minimum accept-
able. (Figure 2-27)
Column 3: Status Messages. (Figure 2-27)
+: The station is being used for navigation.
-: The station is weak or unacquired.
TOO FAR:
The station is not used because of its distance from the aircraft posi-
tion.
WSH 99 +
AUS 00 TOO FAR
ANT 99 +
MNE 99 +
HAW 99 +
JPN 99 SPARE
GBR‘ 99 +
ANN 99 +
VLF SUBSECTION 3/4
<
<
<
<
Figure 2-27
