CONFIGURING MAXPRO NVR
Configuring the Cameras
102 MAXPRO NVR 3.1 Operator’s Guide
4
5. Under Live Quality Settings
• Select the Video Format (NTSC or PAL).
•The Compression Format is defaulted to a fixed value based on the camera model.
• By default the highest supported Resolution (720 X 480) is selected with maximum
frame rate supported by the card.
• Select the FPS for a camera. FPS refers to the number of pictures displayed in
exactly one second. FPS is a measure of how much information is used to store and
display motion video. The term applies to digital video. Each frame is a still image;
displaying frames in quick succession creates the illusion of motion.
• Type the Hardware ID, if the analog camera type is a PTZ camera. The hardware ID
is based on the PTZ Protocol.
Note: Based on the model, Analog Capture card supports only 480 frames @ CIF. By
default all the 16 cameras will be added. You can add/remove the number of
cameras based on the range of FPS and supported resolution.
• Select the PTZ Sensitivity for a PTZ camera. Available PTZ options are: Low,
Normal, High and Maximum. For advanced PTZ settings see Advanced PTZ
Settings section.
•The Compression is defaulted to “Medium”. You can select a new Compression
ratio as applicable.
6. Under Record Quality Settings
• Select the FPS for Continuous recording.
• Select the FPS for Event based recording.
By default GOP is equivalent to FPS (1 I-frame per second).
7. Under Recording Deletion Settings
• Select the Event Recording clip deletion duration.
• Select the Continuous Recording clip deletion duration.
Caution: For Recording Deletion Settings, please exercise caution with Keep
Forever clip deletion duration setting. Recordings with Keep Forever are
stored permanently and are not deleted/overwritten even if the disk
becomes full. They can be deleted only manually from the Search tab.
8. Click Video Display Settings. The Color Correction dialog box appears.
Note: The Video Display Settings feature is available only on the desktop local client
on the NVR Hybrid Server machine.
