LOGGING ON AND FAMILIARIZATION
Familiarizing with the MAXPRO NVR User Interface
MAXPRO NVR 3.1 Operator’s Guide 53
Configurator Tab
The following figure illustrates the Configurator tab.
Figure 3-8 Configurator tab
The settings in the Configurator tab enable you to add and configure the video devices and
set up the MAXPRO NVR system.
Components Description
System tab Helps you to configure the system level
information for MAXPRO NVR.
Disk tab Helps you to configure the disk settings for
video storage.
Camera tab Helps you to configure the camera settings.
Schedules tab Helps you to configure the schedules for live
video.
IO tab Helps you to configure the input and output
for a camera.
Sequence tab Helps you to select a sequence of cameras
for live video.
User tab Helps in user administration.
