Using Instrument Functions
Customizing the Display
Measurement title and
The measurement title area consists of two lines of text. In the default
clock or preset state, this annotation area is toggled off. When the title
mode is initially turned on - by pressing (j-1 MOB Wisp&y
Titls a& Clock - line 1 is empty and the clock (date and time of day) is
assigned to line 2.
The Title and Glo& menu allows you to customize these two lines. The
clock can be shown on line 1, line 2, or can be turned off. You can enter up
to 30 characters of text on either or both lines.
NOTE
When the display is in split display mode, line 1 is shown at the top of the measurement channel 1
screen, and line 2 is shown at the top of the measurement channel 2 screen.
lb turn the measurement title and clock on or off, press [F)
More llisplay Title and Glo& Titlo*C1R QN oif.
Measurement Channel The measurement channel annotation at the top of the display screen can
Annotation be modified through the use of SCPI commands. See Chapter 7 for more
information.
To turn the measurement channel annotation on or off, press c-1
Mare Ditrplay Bnaotatim Qptfcms Gas Annat ON dv .
Frequency Annotation The frequency annotation at the bottom of the display (X-axis) can be
modihed through the use of SCPI commands. See Chapter 7 for more
information.
‘lb turn the measurement channel annotation on or off, press (DISPLAY)
?ttava Display Amwtatim Clptiofts Freq Artftot QN oi9 .
4-60
