Calibrating for Increased Measurement
Accuracy
Check the Calibration
Transmission
Transmission tracking is a transmission measurement error
Tracking term. It is a measure of the corrected THRU standard.
A typical transmission tracking error is fO.1 dB. Most likely
this term wilI be dominated by trace noise.
W: Memory W: Memory
D2: Off D2: Off
Log Mag Log Mag 0.1 dB/ Ref 0.1 dB/ Ref 0.00 d’d C 0.00 d’d C
StartStart 0.3000.300 MHZMHZ
St00St00 11 300.000300.000
MHZ MHZ
Figure 6-6. Typical Transmission Tracking Error TermFigure 6-6. Typical Transmission Tracking Error Term
