Disp
FrBq
Softkey
in
m
menu.
Selects the resolution of the displayed frequency
&?SOlUt
iUA
resolution as MHz,
kHz,
or Hz. For example, a frequency of
1,234,567
Hz can
be displayed as: 1 MHz (note rounding down), 1.235 MHz (note rounding up),
or 1.234 567 MHz. Default is
kHz.
(-1
Hardkey in CONFIGURE area of front panel. Displays menu with selections
concerning type of data to be displayed, split or full screen, title and limit
lines.
X)istmc@
(Option 100
only)
Softkey
available under the
m
key and the add
max point and add min point menus. Used to perform fault location
measurements. See your Option 100 User’s Guide Supplement for
information.
Dither:
Softkey
in spur avoid options menu. When selected, shifts spurs which may
be visible in low level measurements.
See “Reducing Trace Noise” in Chapter 5 for more information.
CAUTION
The measurement calibration must be performed with the same spur avoid
option used in the measurement or your results may be invalid.
Access Keys:
IrVIENU)
$pr~ Avoid Options
Do
CAL
Softkey
in the cal check menu. Initiates a calibration check.
Check
See Chapter 6 for more information on using cal check.
Access Keys:
a
C&1
Check
DTRJDSR
Softkey
in select copy port menu. A hardware handshake for some serial
devices. Toggles with
Xon/Xoff
.
Access Keys:
[HARD]
Selsct
@oPy
Port
9-23
