I
-
Getting Started
Entering Measurement Parameters
Scaling the
Measurement Trace
1. Press the ~ZKCEJ key to access the scale menu.
2. lb view the complete measurement trace on the display, press
Autoscals .
3. lb change the scale per division to 5 dB/division press Scals/Ri~ Q
Enter.
4. ‘R I move the reference position (indicated by the ) symbol on the left side
of the display) to the first division down from the top of the display, press
Refex*ace Pusitioa @ Enter.
Figure 2-3 shows how each reference
position is identified.
5. To change the reference level to 0 dE%, press R~&XE%WXI L%v&t @
l&rfz%X .
10
9
8
7
6
5
4
3
2
1
0
po’352b-c
Figure 2-3. Reference Positions
2-9
-1
