• Full length PCIe SAS card with RAID capability, supported on HP-UX, OpenVMS, Windows
and Linux, see“Installing the HP Smart Array P400” (page 266) for installation instructions.
• Full length PCIe SAS card with RAID capability, able to connect to external storage,
supported on Windows and Linux, see “Installing the HP Smart Array P800” (page 270)
for installation instructions.
9. Installing the New I/O Backplane
IMPORTANT: System information is stored on the I/O board assembly. You must write the
serial number and model string information to the new I/O board after installation.
See “Replacing the I/O Board Assembly” (page 225) for this procedure.
10. Powering On the Server. See “Powering On the Server” (page 90) for this procedure.
Procedure 5 Verification from EFI
1. Respond YES to prompts regarding copying information onto the new board.
2. Verify the serial number and model string data information copied onto the new I/O
board.
a. Boot to EFI.
b. Enter service mode using the following command:
Shell> sysmode service
Current System Mode: ADMIN
You are now in SERVICE mode.
c. Use the sysset command to verify that all values are set:
Shell> sysset
System Information:
Manufacturer: hp
Product Name: server rx3600
Product Number: AB463A
Secondary Product Number is Identical
Serial number: SGH43442VB
Secondary Serial Number is Identical
UUID: 3C33C58E-2E5A-11D8-A33B-4188C0AEFAE2 (Valid)
Secondary UUID is Identical
Product ID: 0x301
3. Enable the TPM.
a. Access the EFI Shell.
b. Enter info sec to display the server security settings on the screen. The TPM is
disabled by default.
c. Enter secconfig to display a list of configurable security settings.
d. Enter secconfig tpm on to enable the TPM.
4. Verify the system board replacement and operation using either the iLO 2 MP or EFI
commands.
11. Viewing Warnings
To view warning access the EFI shell and run the info warning command.
12. Verifying I/O cards
To verify the I/O cards access the EFI shell and run the info io command.
Shell> info io
I/O INFORMATION
BOOTABLE DEVICES
Order Media Type Path
----- ---------- ---------------------------------------
1 CDROM Acpi(HWP0002,PNP0A03,0)/Pci(2|1)/Usb(0, 0)/CDROM(Entry0)/HD(Part1,Sig00000000)
2 HARDDRIVE
Acpi(HWP0002,PNP0A03,400)/Pci(2|0)/Sas(Addr5000C5000034749D,Lun0)/HD(Part1,Sig4EE76936-BE45-47FA-9AC7-B0ECF2D912F2)
262 Upgrades
