8-15
Time Protocols
TimeP: Viewing, Selecting, and Configuring
Figure 8-9. The System Information Screen (Default Values)
2. Press (for
Edit). The cursor moves to the System Name field.
3. Use [v] to move the cursor to the
Time Sync Method field.
4. If
TIMEP is not already selected, use the Space bar to select TIMEP, then
press [v] once to display and move to the
TimeP Mode field.
5. Do one of the following:
• Use the Space bar to select the
DHCP mode, then press [v] to move
the cursor to the
Poll Interval field, and go to step 6.
• Use the Space bar to select the
Manual mode.
i. Press [>] to move the cursor to the
Server Address field.
ii. Enter the IP address of the TimeP server you want the switch to
use for time synchronization.
Time Protocol Selection Parameter
– TIMEP (the default)
–SNTP
– None
!Software.book Page 15 Thursday, October 10, 2002 6:10 PM
