10-2
Configuring for Network Management Applications
Using SNMP Tools To Manage the Switch
Using SNMP Tools To Manage the Switch
Overview
You can manage the switch via SNMP from a network management station,
including HP TopTools for Hubs & Switches — a network management
application that runs on your Windows NT- or Windows 2000-based PC. HP
TopTools for Hubs & Switches provides control of your switch through its web
browser interface. In addition, it uses the RMON agent statistical sampling
software that is included in the switch to provide easy-to-use traffic monitor-
ing and network activity analysis tools. For more on TopTools, see the "Read
Me First" document shipped with your switch and also available on HP’s
Procurve website at
http://www.hp.com/go/hpprocurve
This section includes:
■ An overview of SNMP management for the switch
■ Configuring the switches for:
• SNMP Communities (page 10-4)
• Trap Receivers and Authentication Traps (page 10-8)
■ Information on advanced management through RMON Support (page
10-12)
To implement SNMP management, the switch must have an IP address,
configured either manually or dynamically (with DHCP or Bootp). If multiple
VLANs are configured, each VLAN interface should have its own IP address.
For DHCP use with multiple VLANs, see “The Primary VLAN” on page 11-7.
Note If you use the switch’s Authorized IP Managers and Management VLAN
features, ensure that the SNMP management station and/or the choice of
switch port used for SNMP access to the switch are compatible with the access
controls enforced by these features. Otherwise, SNMP access to the switch
will be blocked. For more on Authorized IP Managers, refer to the Access
Security Guide on the Documentation CD-ROM shipped with your switch and
also available on the HP Procurve web site. For information on the Manage-
ment VLAN feature, refer to “The Secure Management VLAN” on page 11-26.
!Software.book Page 2 Thursday, October 10, 2002 6:10 PM
