B-18

Monitoring and Analyzing Switch Operation

Status and Counters Data

Internet Group Management Protocol (IGMP) Status

The switch uses the CLI to display the following IGMP status on a per-VLAN

basis:

For example, suppose that show ip igmp listed an IGMP group address of

224.0.1.22. You could get additional data on that group by executing the

following:

Figure B-13. Example of IGMP Group Data

Show Command Output

show ip igmp Global command listing IGMP status for all VLANs configured

in the switch:

• VLAN ID (VID) and name

• Active group addresses per VLAN

• Number of report and query packets per group

• Querier access port per VLAN

show ip igmp <vlan-id> Per-VLAN command listing above IGMP status for specified

VLAN (VID)

show ip igmp group <ip-addr> Lists the ports currently participating in the specified group,

with port type, Access type, Age Timer data and Leave Timer

data.

HPswitch> show igmp group 224.0.1.22

IGMP ports for group 224.0.1.22

Port Type Access Age Timer Leave Timer

---- --------- ---------- --------- -----------

3 10/100TX host 0 0

!Software.book Page 18 Thursday, October 10, 2002 6:10 PM
