1-3

Selecting a Management Interface

Advantages of Using the Menu Interface

Figure 1-1. Example of the Console Interface Display

■ Provides quick, easy management access to a menu-driven subset of

switch configuration and performance features:

The menu interface also provides access for:

■ Offers out-of-band access (through the RS-232 connection) to the

switch, so network bottlenecks, crashes, lack of configured or correct IP

address, and network downtime do not slow or prevent access

■ Enables Telnet (in-band) access to the menu functionality.

■ Allows faster navigation, avoiding delays that occur with slower

display of graphical objects over a web browser interface.

■ Provides more security; configuration information and passwords are

not seen on the network.

• IP addressing

• VLANs and GVRP

• Port Security

• Port and Static Trunk Group

• Stack Management

• Spanning Tree

• System information

• Passwords

• SNMP communities

• Time protocols

• Setup screen

• Event Log display

• Switch and port

status displays

• Switch and port statistic and counter

displays

• Reboots

• Software downloads

!Software.book Page 3 Thursday, October 10, 2002 6:10 PM
