10-19
Configuring for Network Management Applications
CDP
CDP-disabled switch) does not forward CDP packets; i.e. is not transparent
to CDP traffic. (For the same reason, switch “E” does not have any CDP
neighbors.)
Figure 10-7 (page 10-17) illustrates how multiple CDP neighbors can appear
on a single port. In this case, switch “A” has three CDP neighbors on port 1
because the intervening devices are not CDP-capable and simply forward CDP
neighbors data out all ports (except the port on which the data was received).
Default Configuration. In the factory-default configuration, CDP is
enabled and running on all ports. In this case, the holdtime is 180 seconds and
the timer (CDP Transmit Interval) is 60 seconds.
Configuring CDP on the Switch
On a Switch 2650 or 6108 you can:
■ View the switch’s current global and per-port CDP configuration
■ List the current contents of the switch’s CDP Neighbors table (that is,
view a listing of the CDP devices of which the switch is aware)
■ Enable or disable CDP (Default: Enabled)
■ Specify the hold time (CDP packet time-to-live) for CDP data deliv-
ered to neighboring CDP devices. For example, in CDP switch "A" you
can specify the hold time for switch "A" entries in the CDP Neighbor
tables of other CDP devices. (Default: 180 seconds)
■ Specify the transmission interval for CDP packets. (Default: 60
seconds)
CLI: Viewing and Configuring CDP
CDP Commands Page
show CDP 10-20
show CDP neighbors 10-20
cdp clear 10-21
[no] cdp run 10-22
[no] cdp enable 10-23
cdp holdtime 10-24
cdp timer 10-24
!Software.book Page 19 Thursday, October 10, 2002 6:10 PM
