HP ProCurve 2650 User Manual

11-1
11
Port-Based Virtual LANs (VLANs) and GVRP
Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3
Port-Based Virtual LANs (Static VLANs) . . . . . . . . . . . . . . . . . . . . . . 11-4
Overview of Using VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-7
Menu: Configuring VLAN Parameters . . . . . . . . . . . . . . . . . . . . . . . . . 11-11
CLI: Configuring VLAN Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . 11-16
Web: Viewing and Configuring VLAN Parameters . . . . . . . . . . . . . . 11-22
VLAN Tagging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-23
The Secure Management VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-27
Effect of VLANs on Other Switch Features . . . . . . . . . . . . . . . . . . . . 11-31
VLAN Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-32
GVRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-34
General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-35
Per-Port Options for Handling GVRP “Unknown VLANs” . . . . . . . . 11-37
Per-Port Options for Dynamic VLAN Advertising and Joining . . . . 11-39
GVRP and VLAN Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-41
Planning for GVRP Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-42
Configuring GVRP On a Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-42
GVRP Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-47
!Software.book Page 1 Thursday, October 10, 2002 6:10 PM

HP ProCurve 2650 Specifications

General

Switching Capacity	13.6 Gbps
Forwarding Rate	10.1 Mpps
Layer	2
Jumbo Frame Support	Yes
Form Factor	Rack-mountable
VLAN Support	Yes
Layer 3 Routing	No
PoE Support	No
Fanless	No
Altitude	Up to 3, 000 meters
Management	CLI, SNMP
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	15% to 95% non-condensing
