13-32

802.1w Rapid Spanning Tree Protocol (RSTP) and 802.1d Spanning Tree Protocol (STP)

802.1p Spanning-Tree Protocol (STP)

To View and/or Configure Fast-Uplink STP. This procedure uses the

Spanning Tree Operation screen to enable STP and to set the Mode for fast-

uplink STP operation.

1. From the Main Menu select:

2. Switch Configuration . . .

4. Spanning Tree Operation

2. In the default STP configuration, RSTP is the selected protocol version.

If this is the case on your switch, you must change the Protocol Version

to STP in order to use Fast-Uplink STP:

Figure 13-14. The Default STP Screen With the Protocol Version Field Set to “RSTP”

• If the Protocol Version is set to RSTP (the default, as shown in this

example, go to step 3.

• If the Protocol Version is set to STP, the rest of the screen will appear

as shown in figure 13-16. In this case, go to step 4 on page 13-34.
