802.1w Rapid Spanning Tree Protocol (RSTP) and 802.1d Spanning Tree Protocol (STP)

802.1p Spanning-Tree Protocol (STP)

Figure 13-21. Example of a Show Spanning-Tree Listing for the Topology Shown in Figure 13-20

Indicates that Trk1 (Trunk 1)

provides the currently active path

to the STP root device.

Redundant STP link in the Blocking

state.

Links to PC or Workstation End

Nodes

Redundant STP link in the

Forwarding state. (See the “Root

Port field, above. This is the

currently active path to the STP

root device.)
