2-11

Using the Menu Interface

Screen Structure and Navigation

To get Help on individual parameter descriptions. In most screens

there is a Help option in the Actions line. Whenever any of the items in the

Actions line is highlighted, press , and a separate help screen is displayed.

For example:

Figure 2-5. Example Showing How To Display Help

To get Help on the actions or data fields in each screen: Use the arrow

keys ([<], [>], [^], or [v]) to select an action or data field. The help line under

the Actions items describes the currently selected action or data field.

For guidance on how to navigate in a screen: See the instructions provided

at the bottom of the screen, or refer to “Screen Structure and Navigation” on

page 2-9.)

Pressing or highlighting Help and

pressing displays Help for the

parameters listed in the upper part of

the screen

Highlight on any item

in the Actions line

indicates that the

Actions line is active.

The Help line provides

a brief descriptor of

the highlighted Action

item or parameter.

!Software.book Page 11 Thursday, October 10, 2002 6:10 PM
