20
Examples
# Display the monitoring results of all reaction entries of the ICMP echo operation with administrator
name admin and operation tag test.
<Sysname> display nqa reaction counters admin test
NQA entry (admin admin, tag test) reaction counters:
Index Checked Element Threshold Type Checked Num Over-threshold Num
1 probe-duration accumulate 12 4
2 probe-duration average - -
3 probe-duration consecutive 160 56
4 probe-fail accumulate 12 0
5 probe-fail consecutive 162 2
Table 7 Command output
Field Description
Index ID of a reaction entry.
Checked Element
Monitored performance metric.
The available performance metrics vary by NQA operation
type. For more information, see Table 8 and Table 9.
Threshold Type Threshold type.
Checked Num
Number of targets that have been monitored for data
collection.
Over-threshold Num Number of threshold violations.
Table 8 Monitored performance metrics for DHCP/DLSw/DNS/FTP/HTTP/ICMP
echo/SNMP/TCP/UDP echo operations
Monitored
performance
metric
Threshold
type
Collect data in Checked Num Over-threshold Num
probe-duration
accumulate
Probes after the
operation starts.
Number of
completed probes.
Number of probes with
duration exceeding the
threshold.
average N/A N/A N/A
consecutive
Probes after the
operation starts.
Number of
completed probes.
Number of probes with
duration exceeding the
threshold.
probe-fail
accumulate
Probes after the
operation starts.
Number of
completed probes.
Number of probe failures.
consecutive
Probes after the
operation starts.
Number of
completed probes.
Number of probe failures.
Table 9 Monitored performance metrics for ICMP jitter/UDP jitter/voice operations
Monitored
performance
metric
Threshold
type
Collect data in Checked Num Over-threshold Num
RTT accumulate
Packets sent
after the
operation starts.
Number of sent
packets.
Number of packets with
round-trip time exceeding
threshold.
