hello-option neighbor-tracking
The function of tracking downstream neighbors is enabled.
After this function is enabled, information about the downstream neighbor who has
sent a Join message and whose Join state does not times out is recorded.
NOTE
The function of tracking downstream neighbors cannot be implemented unless all the switchs
running IPv6 PIM-SM in the shared network segment are enabled with this function.
l Configuration on an Interface
1. Run:
system-view
The system view is displayed.
2. Run:
interface interface-type interface-number
The interface view is displayed.
3. Run:
pim ipv6 hello-option neighbor-tracking
The function of tracking downstream neighbors is enabled.
After this function is enabled, information about the downstream neighbor who has
sent a Join message and whose Join state does not times out is recorded.
NOTE
The function of tracking downstream neighbors cannot be implemented unless all the switchs
running IPv6 PIM-SM in the shared network segment are enabled with this function.
----End
13.6.5 Configuring PIM Neighbor Filtering
To prevent some unknown devices from being involved in PIM, filtering PIM neighbors is
required. An interface sets up neighbor relationships with only the addresses matching the
filtering rules and deletes the neighbors unmatched with the filtering rules.
Context
To prevent some switch from being involved in the PIM protocol and prevent this switch from
becoming the DR, filtering PIM neighbors is required.
Do as follows on the switch enabled with IPv6 PIM-SM:
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
interface interface-type interface-number
Quidway S7700 Smart Routing Switch
Configuration Guide - Multicast 13 PIM-SM (IPv6) Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
474
